Industrial Canning Retorts

Name: Industrial Canning Retorts
Brand: UNIVERSAL ENGINEERS
Price: 80000.0 INR
Availability: InStock

Price 80000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Industrial Canning Retorts Specification

Connectivity Options
PLC and Touchscreen HMI

Machine Type
Batch Type Retort

Frame Type
Heavy-duty steel frame

Features
Energy efficient, multi-layer protection, uniform heating, PLC based controls

Model No
RT-IND-2200

Voltage
380V / 415V Volt (v)

Frequency
50 Hz / 60 Hz Hertz (HZ)

Motor Power
3 kW Kilowatt (kW)

Noise Level
<70 dB db

Drive
Electric Motor Drive

Cooling System
Integrated water cooling

Lubricating System
Automatic greasing

Power Rating
3-phase / 415V System

Operating Temperature
Up to 130C Celsius (oC)

Product Type
Industrial Canning Retort

Technology
Steam and Water Spray

Power Source
Electric

Pressure
Up to 2.5 bar Bar

Surface Treatment
Polished Stainless Steel

Dimension (L*W*H)
2000 x 1200 x 1800 mm Millimeter (mm)

Weight (kg)
1500-2500 kg Kilograms (kg)

Color
Metallic Silver

Warranty
1 year

Usage & Applications
Food canning, beverage canning, seafood canning, ready-to-eat packaging

Operator Training
On-site/Remote available

Batch Size
Customizable per requirement

Water Consumption
150-300 L/cycle

Sterilization Cycle Time
35-100 min (depending on load)

Installation Type
Skid mounted

Maintenance Requirements
Low, designed for easy servicing

Chamber Configuration
Horizontal cylindrical

Compliance
CE, ISO9001 certified

Safety Features
Pressure relief valves, safety interlocks, alarms

Temperature Uniformity
0.5C

Steam Consumption
80-150 kg/h

Gasket Material
Silicone/Food Grade Rubber

Retort Door Type
Quick locking or swing bolt

User Interface
Color touch panel, multi-language support

Optional Accessories
Data logger, remote monitoring, extra racks

Industrial Canning Retorts Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cheque

Supply Ability
50 Units Per Month

Delivery Time
3 Week

Main Export Market(s)
Middle East, Africa, South America, Eastern Europe, Western Europe, Asia, Australia, Central America, North America

Main Domestic Market
All India

About Industrial Canning Retorts

Installed for the purpose of performing the functionality of sterilizing this Industrial Canning Retorts is installed in the units. We as a established firm are indulged in making this Industrial Canning Retorts at utmost priority. It is made in such a manner that it can be installed with ease. It gets into act in a very quick time slot and performs the whole process in an effective manner. The delivery of the same is done at a very decent price rate.

Product Details

Voltage	220 V
Available Material	MS, SS
Surface Finishing	Polished

Advanced Features for Reliable Sterilization

With steam and water spray technology, the RT-IND-2200 ensures uniform heating and accurate sterilization up to 130C. CE and ISO9001 certified, this retort offers batch cycle times of 35-100 minutes and is equipped with pressure relief valves, safety interlocks, and alarms for multi-layer protection, making it suitable for stringent industrial standards.

Customizable and User-Friendly Design

From customizable batch sizes and chamber dimensions to intuitive color touchscreen controls, the retort adapts to specific production needs. The heavy-duty steel frame, polished stainless-steel surfaces, and automatic greasing system guarantee durability and minimal maintenance. Operators benefit from on-site or remote training and easy, skid-mounted installation.

Efficient Operation with Modern Connectivity

Supporting up to 2,000 cans per cycle, the RT-IND-2200 maximizes productivity while keeping water, steam, and energy consumption low. With PLC connectivity, data logging, and remote monitoring optional, integration and process tracking are streamlined, paving the way for enhanced process management and documentation.

FAQs of Industrial Canning Retorts:

Q: How does the RT-IND-2200 retort ensure uniform temperature during sterilization?

A: The retort utilizes advanced steam and water spray technology managed by a PLC-based control system. This setup, along with effective circulation and precise monitoring, maintains temperature uniformity within 0.5C throughout the chamber, preserving product quality and safety.

Q: What benefits does the quick-lock or swing-bolt door mechanism offer?

A: Both door types allow for rapid, secure closure, reducing downtime during loading and unloading cycles. Combined with food-grade silicone or rubber gaskets, they ensure leak-proof, hygienic operation essential for safe food processing.

Q: Where can the RT-IND-2200 be installed, and how complex is the installation process?

A: The retort is designed for industrial settings, suitable for food, beverage, and seafood canning facilities. Its skid-mounted construction allows for efficient transport and straightforward installation, requiring only standard utilities (3-phase/415V power and water supply).

Q: What operator support and training options are provided?

A: Comprehensive operator training is available both on-site and remotely, covering equipment operation, safety protocols, and maintenance procedures. Multi-language support on the touchscreen interface further facilitates user training and daily operation.

Q: What safety measures are integrated into the retort system?

A: The RT-IND-2200 prioritizes safety with pressure relief valves, safety interlocks, and alarms that monitor and alert for irregular operating conditions. These features, alongside robust frame construction and certified compliance, ensure a secure working environment.

Q: When is the optional data logger and remote monitoring useful?

A: The data logger and remote monitoring options are valuable for quality assurance, regulatory compliance, and process optimization. They enable tracking of sterilization parameters, remote diagnostics, and real-time process review, ideal for audits or multi-site production management.

Q: What are the maintenance requirements for this canning retort?

A: Designed for easy servicing, the retort features automatic greasing, polished surfaces for simplicity in cleaning, and accessible components. Minimal interruptions are expected, supporting continuous, dependable operation with low maintenance demands.
